10940111 | bda connectivity
Coax RF cable, 50 Ω (50R), white, Staku stranded wire, silver-plated, 10940111
Unit Price (€ / mtr.)
4.1650 € *
Available: 326 mtr.
Total Price:
4.17 € *
Price list
Quantity
Price per unit*
1 mtr.
4.1650 €
10 mtr.
3.6771 €
100 mtr.
3.2249 €
200 mtr.
3.1059 €
800 mtr.
2.8917 €
*incl. VAT plus shipping costs
Subject to prior sale
Coax RF cables, Teflon insulation, 50 ohm to MiL-C-17, type RG 188 A/U.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Impedance | 50 Ω | |
| Material | FEP | |
| Colour | white | |
| Outer diameter | 2.5 mm | |
| Cable material | copper, silver-plated | |
| Cable structure | 7 x 0.17 mm | |
| Shielding | shielded | |
| Dielectric material | FEP | |
| Dielectric diameter | 1.5 mm | |
| Capicity/m | 95 pF/m | |
| min. operating temperature | -55 °C | |
| max. operating temperature | 205 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | EG |
| Original Packaging | Reel with 100 meters |
| Customs tariff number | 85442000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
