L21AE01 | BACO
Mushroom pushbutton, unlit, groping, waistband round, red, mounting Ø 70 mm, L21AE01
Unit Price (€ / pc.)
22.3125 € *
Standard delivery time from the manufacturer is: 2 Weeks
Mushroom head pushbutton, red, for control and signal gear, 22 and 30 mm, series BACO
Type: L21AE01
With mounting nut, for combination with adapter and contact elements, 22 mm actuator with momentary action; Degree of protection: IP 66. Certification: UL. Operating temperatures: - 25 to +70 °C.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Installation diameter | 70 mm | |
| Protection class | IP69K | |
| can be illuminated | No | |
| Installation height | 22 mm | |
| Contact function | groping | |
| Collar shape of the front frame | round | |
| Actuator colour | red | |
| Type of mounting | threaded ring | |
| Product type | mushroom pushbutton |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85389099 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
