L21AA05 | BACO
Pushbutton, unlit, groping, waistband round, white, mounting Ø 22 mm, L21AA05
Unit Price (€ / pc.)
6.4736 € *
Standard delivery time from the manufacturer is: On Request
Flat pushbutton, not illuminated, white, no legend, for control and signal gear, 22 mm, series BACO
Type: L21AA05
With mounting nut and chromed front bezel, for combination with adapter and contact elements, 22 mm actuator with momentary action; Degree of protection: IP 66. Certification: UL. Operating temperatures: - 25 to +70 °C.
Technical specifications
| Installation height | 11 mm | |
| Contact function | groping | |
| Installation diameter | 22 mm | |
| Type of mounting | threaded ring | |
| Actuator colour | white | |
| Product type | pushbutton | |
| Protection class | IP69K | |
| Collar shape of the front frame | round | |
| can be illuminated | No |
Download
Logistics
| Country of origin | PL |
| Customs tariff number | 85389099 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
