EMZ802 | AUTH
Line filter, 20 kHz to 500 MHz, 1 A, 250 VAC, 250 W, print terminal, EMZ802
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
111.2293 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
111.23 € *
Price list
Quantity
Price per unit*
1 pcs.
111.2293 €
5 pcs.
107.6355 €
10 pcs.
100.4598 €
50 pcs.
93.2841 €
100 pcs.
86.1084 €
*incl. VAT plus shipping costs
Subject to prior sale
Universal broadband mains filters, type AUTH EMZ 802.
High attenuation and broadband RF interference suppression, with ground conductor choke, shielded metal housing for EMC/EMI suppression, fuse; Rated voltage: 110 to 250 VAC, 50/60 Hz. Connection: 1.5 mm² terminal strip. Dimensions: 36 x 63 x 114 mm. Selection of maximum filter bandwidth in relation to the max. current rating.
Technical attributes (type, rated current, blocking range, . filter attenuation): EMZ 802, 2.0 A, 20 kHz to 500 MHz, 10 to 70 dB
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | line filter | |
| min. frequency | 20 kHz | |
| max. frequency | 500 MHz | |
| Rated current | 1 A | |
| Rated Voltage | 250 VAC | |
| Power | 250 W | |
| Connection | print terminal | |
| With fuse | Yes | |
| integrated switch | No | |
| min. operating temperature | -25 °C | |
| max. operating temperature | 50 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85363010 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
