EMZ516 | AUTH
Line filter, 200 kHz to 200 MHz, 16 A, 250 VAC, 4 kW, earthing contact (CEE 7/4), EMZ516
Unit Price (€ / pc.)
86.9295 € *
Available: 3 pcs.
Total Price:
86.93 € *
Price list
Quantity
Price per unit*
1 pcs.
86.9295 €
5 pcs.
84.1330 €
10 pcs.
78.5162 €
50 pcs.
72.9113 €
100 pcs.
67.3064 €
*incl. VAT plus shipping costs
Subject to prior sale
Universal EMC filter adapters, EMZ 516, AUTH
The EMZ 516 is a universal interference suppression filter for fast external retrofitting of electrical devices. This product is suitable for the reduction of broadband interference emissions both from as well as into the mains network. Also includes line network absorbs high-frequency voltages from motors, switches, switching power supplies or oscillators, which can negatively influence devices in their function.
Features
- Protective contact
- Overvoltage protection optional
- Quick to plug in
- Ground wire choking
- Compact and stable housing
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | earthing contact (CEE 7/4) | |
| With fuse | Yes | |
| min. frequency | 200 kHz | |
| max. frequency | 200 MHz | |
| Rated Voltage | 250 VAC | |
| max. operating temperature | 40 °C | |
| Power | 4 kW | |
| min. operating temperature | -25 °C | |
| Version | line filter | |
| integrated switch | No | |
| Rated current | 16 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85363010 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
