Q- 22,118400M-HC49US-F-30-30-D-16 | Auris

Crystal, 22.1184 MHz, 16 pF, ±30 ppm, 35 Ω, THT

Order No.: 78D160
EAN: 4099879149381
MPN:
Q- 22,118400M-HC49US-F-30-30-D-16
Series: HC49US
Auris
default L
Image may differ
Print
Key Specification:
Frequency 22.1184 MHz
Frequency stability +/-30
Tolerance ±30 ppm
Load Capacity 16 pF
ESR (Equivalent Series Resistance) 35 Ω
Show 43 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
0.4879 € *
Available: 1,068 pcs.
Leadtime: 10 Weeks **
Total Price:
4.88 € *
Price list
Quantity
Price per unit*
10 pcs.
0.4879 €
50 pcs.
0.3451 €
250 pcs.
0.2892 €
1000 pcs.
0.2475 €
2500 pcs.
0.2178 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

Miniature quartz crystals, type Auris HC49US.

Frequency tolerance: ±30 ppm at +25 °C. Temperature tolerance: 30 ppm. Operating temperatures: –20 to +70 °C. Parallel capacitance: max. 7.0 pF. Insulation resistance: 500 Mohm. Aging: ±5.0 ppm/year.


Type: 22.118400 MHz, 16 pF
Technical specifications
Width 4.7 mm
ESR (Equivalent Series Resistance) 35 Ω
Frequency 22.1184 MHz
Frequency stability +/-30
Height 3.5 mm
Length 11.1 mm
Load Capacity 16 pF
max. operating temperature 70 °C
min. operating temperature -20 °C
Assembly THT
Tolerance ±30 ppm
