RB101 5% 82R | ATE ELECTRONICS
Wirewound resistor, 82 Ω, 100 W, ±5 %, RB101 5% 82R
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
10.4363 € *
Standard delivery time from the manufacturer is: 8 Weeks
Mit 100 Watt Toleranz 5,0 % Typ ATE RB 101.
Nennbelastbarkeit mit/ohne Kühlfläche: 100/40 Watt, Grenzspannung: 1900 V, Durchschlagfestigkeit: 3500 VAC, Isolationswiderstand: 10 GOhm, Überlast: 5fache Nennlast für 5,0 s. Maße: A 47,5 B 89, C 24, D 27, E 64, F 35, G 37, H 11,5, J 14,5 K 3,5, L 4,4, N 3,0, Anschluss: Durchmesser 3,2 mm.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ohmic resistance | 82 Ω | |
| Tolerance | ±5 % | |
| Power | 100 W | |
| Design | chassis | |
| Assembly | chassis mounting | |
| Version | high load wire resistor | |
| Temperature coefficient | 30 ppm/K | |
| min. operating temperature | -55 °C | |
| max. operating temperature | 250 °C | |
| nominal load capacity without cooling surface | 40 W | |
| Length | 64 mm | |
| Width | 47.5 mm | |
| Height | 24 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 85332100 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
