6-160316-4 | AMP

Name: Uninsulated flat plug sleeve, 2.8 x 0.51 mm, 0.32 to 0.51 mm², AWG 22 to 20, brass, tin-plated, 6-160316-4
Brand: AMP
SKU: 34P8193
Availability: InStock

Uninsulated flat plug sleeve, 2.8 x 0.51 mm, 0.32 to 0.51 mm², AWG 22 to 20, brass, tin-plated, 6-160316-4

Order No.: 34P8193

EAN: 4099889622218

MPN:

6-160316-4

Image may differ

Key Specification:

Version flat plug sleeve

Suitable for 2.8 x 0.51 mm

Material brass, tin-plated

Isolated No

Ordering Information:

not to be sold to private customers

Download Datasheet Technical specifications

NCNR (non cancelable / non returnable)

Unit Price (€ / pc.)

0.1059 € *

Available in 12 Days: 10,000 pcs. - if ordered today

Total Price:

1,059.10 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Flat receptacle, 6-160316-4, TE Connectivity

Terminates To: Wire & Cable, Insertion Force: Normal, Sealable: No, Insulated: No, Connection Capacity: Single, Fully Insulated: No, Plating Material: Tin, Terminal Type: Receptacle, Terminal & Splice Type: Receptacle, Terminal Orientation: Straight, Contact Base Material: Brass, Crimp Type: F-Crimp, Wire Insulation Support: With, Receptacle Terminal Stock Thickness: 0.25 mm, Wire Size: 22 – 20 AWG, Wire Size: 0.32 -0.51 mm², Mating Tab Width: 2.8 mm, Mating Tab Thickness: 0.51 mm, Operating Temperature Range: -40 – 110 °C, Packaging Quantity: 10000, Packaging Method: Strip/Reel

Technical specifications

Filter	Property	Value
	Version	flat plug sleeve
	Suitable for	2.8 x 0.51 mm
	Material	brass, tin-plated
	Isolated	No
	Connection	crimp connection
	Cable cross-section	0.32 to 0.51 mm²
	AWG cross-section	AWG 22 to 20
	Length	14 mm
