826656-7 | AMP
Pin header, 14 pole, pitch 2.54 mm, straight, green, 826656-7
Unit Price (€ / pc.)
1.5113 € *
Available: 443 pcs.
Total Price:
1.51 € *
Price list
Quantity
Price per unit*
1 pcs.
1.5113 €
25 pcs.
1.2852 €
100 pcs.
1.2019 €
250 pcs.
1.1424 €
1000 pcs.
1.0472 €
*incl. VAT plus shipping costs
Subject to prior sale
Dual-row pin headers, straight, type TE Connectivity/AMP Modu II.
With 2.54 mm grid; Housing: polyester, green, compliant with UL 94 V-0, self-extinguishing. Contacts: tinned (2.5 µm tin over Ni) or gold-plated (0.8 µm Au over Ni). Dimension C: 3.2 mm. The number of contacts can be reduced as required by breaking them off.
Gold-plated, pin length B 5.8 mm, type ..-0826.
Gold-plated pins in the contact area (0.8 µm Au over 1.3 µm Ni); Gold-plated zone (dimension F): 4.4 mm, tinned solder area (2.5 µm tin over 1.3 µm Ni). Dimension A: 11.5 mm. Dimension C: 2.9 mm.
Type: 0-0826656-7, 2 x 7-pole
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 5 A | |
| Type of locking | Yes | |
| Grid | 2.54 mm | |
| Connection plating | tin-plated | |
| Number of rows | 2 | |
| Orientation | straight | |
| contact surface | gold-plated | |
| Version | pin header | |
| Colour | green | |
| Connection | PCB connection | |
| Breakable | Yes | |
| Pin number | 14 pole | |
| Additional parts | equipped | |
| Contact type | pin |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IN |
| Customs tariff number | 85366930 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
