8-353081-2 | AMP

Pin header, 3 pole, pitch 10.16 mm, angled, black, 8-353081-2

Order No.: 72P1916
EAN: 4099891740047
MPN:
8-353081-2
Series: Dynamic 5000
8-353081-2 AMP PCB Connection Systems Image 1
8-353081-2 AMP PCB Connection Systems Image 2
8-353081-2 AMP PCB Connection Systems Image 3
8-353081-2 AMP PCB Connection Systems Image 4
8-353081-2 AMP PCB Connection Systems Image 5
Image may differ
Unit Price (€ / pc.)
18.2665 € *
Available in 5 Days: 356 pcs. - if ordered today
Total Price:
18.27 € *
Price list
Quantity
Price per unit*
1 pcs.
18.2665 €
10 pcs.
16.8147 €
25 pcs.
15.1249 €
50 pcs.
13.6136 €
*incl. VAT plus shipping costs
Subject to prior sale

PCB Header, 8-353081-2, AMP

PCB Mount header, Horizontal, Wire-to-Board, 3 Position, 10.16 mm Centerline, Fully shrouded, Gold, Through Hole-Solder.

Applications

  • Industrial Control
  • Production Equipment
  • Servo Drives
  • Power Distribution
  • Industrial Process Controls
  • Numeric Controllers
Technical specifications
Colour black
Type of locking Yes
contact surface gold-plated
Rated current 30 A
Grid 10.16 mm
Connection plating tin-plated
Pin number 3 pole
Version pin header
Additional parts equipped
Orientation angled
Connection solder connection
Contact type pin
Rated voltage 630 V
Number of rows 1
Logistics
Country of origin CN
Customs tariff number 85366930
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
