770101-1 | AMP
Plug housing, 12 pole, pitch 5.03 mm, straight, natural, 770101-1
Order No.: 34P6817
EAN: 4099889913552
MPN:
770101-1
Unit Price (€ / pc.)
1.2376 € *
Available in 5 Days: 814 pcs. - if ordered today
PCB Connection System, 770101-1, AMP
Wire-to-Panel, Wire-to-Wire, Wire & Cable, 12 Position
Technical Data
- Connector Mounting Type: Panel Mount
- Contact Type: Male
- Housing Material: Nylon 6/6
- Housing Color: natural
- Number of positions: 12
- Operating Temperature Range: -55 – 105 °C [-67 – 221 °F]
- Centerline (Pitch): 5.03 mm
- Row-to-Row Spacing: 5.03 mm [0.198 in]
- Sealable: No
- Contact Layout: Matrix
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 5.03 mm | |
| Contact type | socket/pin | |
| Additional parts | unequipped | |
| Colour | natural | |
| Rated current | 13 A | |
| Number of rows | 4 | |
| Connection | crimp connection | |
| Pin number | 12 pole | |
| Orientation | straight | |
| Version | plug housing | |
| Type of locking | Yes | |
| Rated voltage | 250 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85389091 |
| Country of origin | CZ |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
