5-826631-0 | AMP

Pin header, 50 pole, pitch 2.54 mm, straight, green, 5-826631-0

Order No.: 59F226
EAN: 4099891005290
MPN:
5-826631-0
5-0826631-0
Series: AMPMODU
5-826631-0 AMP PCB Connection Systems Image 1
5-826631-0 AMP PCB Connection Systems Image 2
5-826631-0 AMP PCB Connection Systems Image 3
5-826631-0 AMP PCB Connection Systems Image 4
5-826631-0 AMP PCB Connection Systems Image 5
Image may differ
Unit Price (€ / pc.)
5.6644 € *
Available: 56 pcs.
Available in 5 Days: 365 pcs. - if ordered today
Total Price:
5.66 € *
Price list
Quantity
Price per unit*
1 pcs.
5.6644 €
10 pcs.
4.9623 €
100 pcs.
4.3792 €
250 pcs.
4.2126 €
*incl. VAT plus shipping costs
Subject to prior sale

Single-row pin headers for PCB mounting, type TE Connectivity/AMP Modu II ..-0826.

With 2.54 mm grid. For Modu IV socket headers without interlock. Insulated housing made of thermoplastic polyester, green, compliant with UL 94 V-0; Contact types: tin bronze contacts, 0.8 µ selective gold-plated on nickel primer (dimension F) and tinned soldering side or brass contacts with tinned contact and solder area. The number of contacts can be reduced as required by breaking them off.

Gold-plated, pin length B 6.7 mm, type ..-0826.

Angled pins, gold-plated in the contact area (0.8 µm Au over 1.3 µm Ni), tinned in the solder area (2.5 µm Sn over 1.3 µm Ni); Dimension A: 2.9 mm. Dimension C: 1.3 mm. Dimension F: 5.5 mm.

Type: 5-0826631-0, 50-pole

Technical specifications
Number of rows 1
Breakable Yes
Additional parts equipped
Contact type pin
Connection PCB connection
Type of locking Yes
Grid 2.54 mm
contact surface gold-plated
Pin number 50 pole
Colour green
Rated current 5 A
Version pin header
Orientation straight
Connection plating tin-plated
Logistics
Country of origin US
Customs tariff number 85366930
Compliance
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free Yes
