4-644615-0 | AMP
Pin header, 10 pole, pitch 3.96 mm, straight, natural, 4-644615-0
Unit Price (€ / pc.)
1.666 € *
Standard delivery time from the manufacturer is: 18 Weeks
Power connector, 4-644615-0, AMP
Rectangular power connector, Header, Plug, Wire-to-Board, 10 Position, 3.96 mm Centerline, Printed circuit board, UL 94V-0.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| contact surface | tin-plated | |
| Type of locking | Yes | |
| Rated current | 7 A | |
| Connection | solder connection | |
| Contact type | pin | |
| Pin number | 10 pole | |
| Rated voltage | 600 V | |
| Grid | 3.96 mm | |
| Version | pin header | |
| Connection plating | tin-plated | |
| Colour | natural | |
| Orientation | straight | |
| Number of rows | 1 | |
| Additional parts | equipped |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
