280359 | AMP
Socket header, 4 pole, pitch 2.54 mm, straight, black, 280359
Unit Price (€ / pc.)
0.2202 € *
Available: 823 pcs.
Available in 5 Days: 102,897 pcs. - if ordered today
Total Price:
22.02 € *
Price list
Quantity
Price per unit*
100 pcs.
0.2202 €
250 pcs.
0.2035 €
500 pcs.
0.1892 €
1000 pcs.
0.1714 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB Connection System, 280359, AMP
Wire-to-Board, Wire & Cable, 4 Position
Technical Data
- Connector Mounting Type: Cable Mount (Free-Hanging)
- Contact Type: Female
- Housing Material: LCP (Liquid Crystal Polymer)
- Housing Color: black
- Orientation: straight
- Number of positions: 4
- Operating Temperature Range: -40 – 80 °C [-40 – 176 °F]
- Rated current: 3 A
- Centerline (Pitch): 2.54 mm
- Row-to-Row Spacing: 2.54 mm [0.1 in]
- PCB Mount Retention: With
- Contact Layout: Inline
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 3 A | |
| Additional parts | unequipped | |
| Version | socket header | |
| Orientation | straight | |
| Grid | 2.54 mm | |
| Number of rows | 1 | |
| Contact type | socket | |
| Colour | black | |
| Pin number | 4 pole | |
| Connection | crimp connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | KR |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
