2204442-1 | AMP
Pin header, 54 pole, pitch 2 mm, angled, black, 2204442-1
Unit Price (€ / pc.)
90.8327 € *
Available in 5 Days: 114 pcs. - if ordered today
Total Price:
90.83 € *
Price list
Quantity
Price per unit*
1 pcs.
90.8327 €
2 pcs.
84.9660 €
5 pcs.
79.8252 €
10 pcs.
74.1965 €
*incl. VAT plus shipping costs
Subject to prior sale
Power connector, 2204442-1, AMP
Rectangular power connector, Header, Plug, Board-to-Board, 54 Position, 5 mm/3 mm/6 mm Centerline.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2 mm | |
| contact surface | gold-plated | |
| Contact type | pin | |
| Connection | press-fit | |
| Connection plating | tin-plated | |
| Rated voltage | 300 V | |
| Orientation | angled | |
| Number of rows | 5 | |
| Pin number | 54 pole | |
| Additional parts | equipped | |
| Colour | black | |
| Version | pin header | |
| Rated current | 75 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85366930 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
