2-292207-4 | AMP
Pin header, 4 pole, pitch 1.5 mm, straight, black, 2-292207-4
Order No.: 71P6351
EAN: 4099891727758
MPN:
2-292207-4
Unit Price (€ / pc.)
0.5831 € *
Available in 5 Days: 6,176 pcs. - if ordered today
Total Price:
2.92 € *
Price list
Quantity
Price per unit*
5 pcs.
0.5831 €
10 pcs.
0.5355 €
25 pcs.
0.4998 €
50 pcs.
0.4522 €
*incl. VAT plus shipping costs
Subject to prior sale
Pin header, 2-292207-4, AMP
PCB Mount header, Vertical, Wire-to-Board, 4 Position, 1.5 mm Centerline, Fully shrouded, Tin, Through Hole - Solder, Signal, Black.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 1.5 mm | |
| Contact type | pin | |
| contact surface | tin-plated | |
| Version | pin header | |
| Rated current | 2 A | |
| Rated voltage | 50 V | |
| Orientation | straight | |
| Type of locking | Yes | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Colour | black | |
| Pin number | 4 pole | |
| Connection | solder connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
