2-179958-2 | AMP

Socket header, 2 pole, pitch 10.16 mm, straight, black, 2-179958-2

Order No.: 38P7421
EAN: 4099889976465
MPN:
2-179958-2
Series: DYNAMIC
2-179958-2 AMP PCB Connection Systems Image 1
2-179958-2 AMP PCB Connection Systems Image 2
2-179958-2 AMP PCB Connection Systems Image 3
2-179958-2 AMP PCB Connection Systems Image 4
2-179958-2 AMP PCB Connection Systems Image 5
Image may differ
Unit Price (€ / pc.)
1.7612 € *
Available in 5 Days: 14,533 pcs. - if ordered today
Total Price:
8.81 € *
Price list
Quantity
Price per unit*
5 pcs.
1.7612 €
10 pcs.
1.6303 €
25 pcs.
1.5232 €
50 pcs.
1.3804 €
*incl. VAT plus shipping costs
Subject to prior sale

PCB Connection System, 2-179958-2, AMP

Wire-to-Board, Wire-to-Panel, Wire-to-Wire, Wire & Cable, 2 Position

Technical Data

  • Connector Mounting Type: Cable Mount (Free-Hanging)
  • Contact Type: Female
  • Housing Material: Polyester GF
  • Housing Color: black
  • Number of positions: 2
  • Operating Temperature Range: -55 – 105 °C [-67 – 221 °F]
  • Centerline (Pitch): 10.16 mm
  • Sealable: No
  • Contact Layout: Inline
Technical specifications
Filter Property Value
Grid 10.16 mm
Contact type socket
Version socket header
Rated current 30 A
Rated voltage 150 V
Orientation straight
Additional parts unequipped
Number of rows 1
Colour black
Pin number 2 pole
Connection crimp connection
Logistics
Property Value
Country of origin CN
Customs tariff number 85472000
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
