1393586-3 | AMP

Pin header, 6 pole, pitch 2.54 mm, straight, gray, 1393586-3

Order No.: 53F2965
EAN: 4099889998160
MPN:
1393586-3
V23535-A2200-A60
1393586-3 AMP PCB Connection Systems
Image may differ
Unit Price (€ / pc.)
3.4153 € *
Standard delivery time from the manufacturer is: 13 Weeks
Total Price:
239.07 € *
*incl. VAT plus shipping costs
Subject to prior sale
70 pcs.
3.4153 €

Compact pin headers, straight, type TE Connectivity/AMP ..-139.

Standard version for PCB mounting, for inserting female connectors DIN 41651 for bus and closed end splices, with center polarity and polarity nipples as well as markings for the first contact; Basic grid: 2.54 mm. Operating current at 20 °C: 1.5 A. Test voltage contact to contact: 0.94 kV. Insulation resistance: at least 100 Gohm. Operating temperatures: –55 to +125 °C. Housing: thermoplastic plastic, glass fiber-reinforced, self-extinguishing in accordance with UL 94 V-0. Contacts: copper alloy, gold over palladium, performance class 2 (at least 200 insertion cycles). Solder pins: tinned over nickel, for 1.0 mm holes, insulation-piercing connecting device: tinned over nickel. The 6-pole version is supplied without polarity nipples and center polarity, the 10- and 14-pole version without polarity nipples. Dimension a (number of poles/2 - 1) x 2.54 mm. Dimension e: a + 7.64 mm.

Technical attributes (type, number of poles, dimension b): 0-1393586-3, 6-pole, b 16.9 mm

Technical specifications
Filter Property Value
Additional parts equipped
Pin number 6 pole
Type of locking No
Grid 2.54 mm
Version pin header
Connection PCB connection
Contact type pin
Rated current 1.5 A
Orientation straight
contact surface gold-plated
Colour gray
Number of rows 2
Logistics
Property Value
Country of origin DE
Customs tariff number 85366990
Compliance
Property Value
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free Yes
