1-1318983-6 | AMP
Pin header, 4 pole, pitch 10.16 mm, angled, black, 1-1318983-6
Unit Price (€ / pc.)
16.1126 € *
Available: 16 pcs.
Available in 5 Days: 1,321 pcs. - if ordered today
Total Price:
16.11 € *
Price list
Quantity
Price per unit*
1 pcs.
16.1126 €
10 pcs.
14.9583 €
25 pcs.
13.9587 €
50 pcs.
12.6973 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB Connection System, 1-1318983-6, AMP
Wire-to-Board, Printed Circuit Board, Shrouded, Right Angle, 4 Position
Technical Data
- Connector Mounting Type: Board Mount
- Contact Type: Male
- Housing Material: Polyester GF
- Housing Color: black
- Orientation: angled
- Number of positions: 4
- Operating Temperature Range: -55 – 105 °C [-67 – 221 °F]
- Rated current: 45 A
- Centerline (Pitch): 10.16 mm
- Row-to-Row Spacing: 10.16 mm [0.4 in]
- PCB Mount Retention: With
- Sealable: No
- Contact Layout: Matrix
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | pin header | |
| Colour | black | |
| Type of locking | Yes | |
| Pin number | 4 pole | |
| Additional parts | equipped | |
| Breakable | No | |
| Connection | PCB connection | |
| Rated voltage | 630 V | |
| Contact type | pin | |
| Rated current | 45 A | |
| Orientation | angled | |
| Grid | 10.16 mm | |
| Number of rows | 2 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CZ |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
