206485-1 | AMP

Plug housing, 9 pole, crimp connection, screw locking, straight, 206485-1

Order No.: 55F3703
EAN: 4099889725735
MPN:
206485-1
0-0206485-1
Series: CPC Series
206485-1 AMP Other Circular Connectors Image 1
206485-1 AMP Other Circular Connectors Image 2
206485-1 AMP Other Circular Connectors Image 3
Image may differ
Unit Price (€ / pc.)
15.4700 € *
Available: 14 pcs.
Available in 5 Days: 1,723 pcs. - if ordered today
Total Price:
15.47 € *
Price list
Quantity
Price per unit*
1 pcs.
15.4700 €
10 pcs.
14.2324 €
50 pcs.
12.9591 €
100 pcs.
11.6620 €
*incl. VAT plus shipping costs
Subject to prior sale

Socket receptacle, bare, with coupling ring for Circular connector, type TE Connectivity/AMP CPC.

For series HDP female contacts, type IIIplus. Housing made of glass fiber-reinforced nylon, black, self-extinguishing to UL 94 VDC1; Certifications: UL, CSA. Corresponding contacts are described at the end of the series.

Receptacle housings, 9-pole, type 11-9.

For female contacts series HDP; Dimensions in mm: M 20.3, N 23.9.

Type: 0-0206485-1, housing 11-9, bare

Technical specifications
Filter Property Value
Assembly cable assembly
Version plug housing
Type of locking screw locking
Contact connection crimp connection
Pin number 9 pole
Additional parts unequipped
Shell Material thermoplastic
Orientation straight
Logistics
Property Value
Country of origin TW
Customs tariff number 85472000
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
