182919-1 | AMP
Socket housing, 4 pole, crimp connection, screw locking, straight, 182919-1
Unit Price (€ / pc.)
8.8774 € *
Available: 19 pcs.
Available in 5 Days: 289 pcs. - if ordered today
Total Price:
8.88 € *
Price list
Quantity
Price per unit*
1 pcs.
8.8774 €
10 pcs.
8.2467 €
25 pcs.
7.6993 €
50 pcs.
6.9972 €
*incl. VAT plus shipping costs
Subject to prior sale
Pin receptacles, bare, without flange for Circular connector, type TE Connectivity/AMP CPC.
Housing made of glass fiber-reinforced nylon, black, self-extinguishing according to UL 94 VDC1. Suitable for use as panel-mount plug and cable plug; Certifications: UL, CSA.
Receptacle housings, 4-pole, type 11-4.
For male contacts type IIIplus; Dimensions in mm: A 34.4, B 10.7, C 2.4, D 17.5, E 19, K 20.6, L 23.6.
Type: 0-0182919-1, housing 11-4, bare
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | cable assembly | |
| Version | socket housing | |
| Type of locking | screw locking | |
| Contact connection | crimp connection | |
| Pin number | 4 pole | |
| Additional parts | unequipped | |
| Shell Material | thermoplastic | |
| Orientation | straight |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | US |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
