5555164-1 | AMP
Socket, RJ45, 8 pole, 8P8C, Cat 3, solder connection, through hole, 5555164-1
Order No.: 37P3148
EAN: 4099889820539
MPN:
5555164-1
Unit Price (€ / pc.)
1.2614 € *
Available: 42 pcs.
Available in 5 Days: 10,730 pcs. - if ordered today
Total Price:
6.31 € *
Price list
Quantity
Price per unit*
5 pcs.
1.2614 €
10 pcs.
1.1662 €
25 pcs.
1.0829 €
50 pcs.
0.9877 €
*incl. VAT plus shipping costs
Subject to prior sale
Modular connector, RJ connector, 5555164-1, AMP
Connector Assembly, RJ45, Jack, Black, -40-85 °C, UL 94V-0, Cat 3
Technical Data
- Modular Connector Style: Jack
- Connector Contact Density: Standard
- Port Matrix Configuration: 1x1
- Contact base material: Phosphor Bronze
- Contact Mating Area Plating Material: Gold
- Panel Mount Feature: With
- Shielded: No
- Connector Height: 12.7 mm
- Centerline (Pitch): 1.02 mm
- Housing Color: black
Technical specifications
| Filter | Property | Value |
|---|---|---|
| RJ-Version | RJ45 | |
| Version | socket | |
| Pole image | 8P8C | |
| Additional parts | equipped | |
| Pin number | 8 pole | |
| Category | Cat 3 | |
| Assembly | through hole | |
| Connection | solder connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TH |
| Customs tariff number | 85366930 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
