106066-2 | AMP
Socket, RJ45, 8 pole, 8P8C, Cat 3, solder connection, through hole, 106066-2
Order No.: 37P3130
EAN: 4099889820362
MPN:
106066-2
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
4.1888 € *
Available in 12 Days: 123 pcs. - if ordered today
Total Price:
4.19 € *
Price list
Quantity
Price per unit*
1 pcs.
4.1888 €
10 pcs.
3.8913 €
25 pcs.
3.6295 €
50 pcs.
3.2963 €
*incl. VAT plus shipping costs
Subject to prior sale
Modular connector, RJ connector, 106066-2, AMP
Connector Assembly, RJ45, Jack, Black, PBT, -40-70 °C, UL 94V-0, Cat 3
Technical Data
- Modular Connector Style: Jack
- Connector Contact Density: Standard
- Port Matrix Configuration: 1x1
- Contact base material: Phosphor Bronze
- Contact Mating Area Plating Material: Gold
- Panel Mount Feature: With
- Shielded: Yes
- Connector Height: 12.05 mm
- Centerline (Pitch): 1.02 mm
- Housing Color: black
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | socket | |
| RJ-Version | RJ45 | |
| Pin number | 8 pole | |
| Pole image | 8P8C | |
| Category | Cat 3 | |
| Connection | solder connection | |
| Additional parts | equipped | |
| Assembly | through hole |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Customs tariff number | 85366930 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
