1-1393203-1 | AMP

Name: Relay, 1 Form C (NO/NC), 24 V (DC), 1.28 kΩ, 7 A, 400 V (AC), monostable, 1-1393203-1
Brand: AMP
SKU: 29G8906
Availability: InStock

Relay, 1 Form C (NO/NC), 24 V (DC), 1.28 kΩ, 7 A, 400 V (AC), monostable, 1-1393203-1

Order No.: 29G8906

EAN: 4099889393828

MPN:

1-1393203-1

V23148-A0007-A101

Series: U/UB

Image may differ

Key Specification:

Contact type 1 Form C (NO/NC)

switching current 7 A

Coil voltage (DC) 24 V

Coil resistance 1.28 kΩ

Download Datasheet Technical specifications

Unit Price (€ / pc.)

11.8405 € *

Available: 12 pcs.

Available in 5 Days: 450 pcs. - if ordered today

Total Price:

11.84 € *

Price list

Quantity

Price per unit*

1 pcs.

11.8405 €

5 pcs.

11.2217 €

10 pcs.

10.4958 €

25 pcs.

9.5676 €

*incl. VAT plus shipping costs

Subject to prior sale

Description

Power relay, type TE Connectivity/Schrack U.

Wash-proof, monostable, standard or sensitive coil; Contact type: 1 x CO. Contact material: AgNi 90/10. Rated voltage: 240 VAC. Switching voltage: max. 400 VAC. Rated current: 7.0 A (standard coil), 5.0 A (sensitive coil). Contact rating: max. 1750 VA (standard coil), 1250 VA (sensitive coil). Dielectric strength coil/contact: 2000 VRMS. Coil power: 450 mW (standard coil), 330 mW (sensitive coil). Response/release time: 5.0/3.0 ms (standard coil), 7.0/3.0 ms (sensitive coil). Relay protection class: RT III. Degree of soiling: 2. Overvoltage category: II. Ambient temperatures: –25 to +70 °C. Certifications: UL, CSA.

With standard coil.

Technical attributes (type, rated coil voltage, coil resistance (±10 %)): 1-1393203-1, 24 VDC, 1280 ohm

Technical specifications

Filter	Property	Value
	Switching Voltage (AC)	400 V
	Connection	PCB connection
	Coil type	monostable
	Contact type	1 Form C (NO/NC)
	Coil voltage (DC)	24 V
	Contact material	AgNi
	switching current	7 A
	Coil resistance	1.28 kΩ
