5207908-1 | AMP
D-Sub connector housing, size: 1 (DE), straight 180°, angled 90°, cable Ø 4.06 mm, PP, black, 5207908-1
Order No.: 37P1685
EAN: 4099889810806
MPN:
5207908-1
Unit Price (€ / pc.)
13.5898 € *
Available in 5 Days: 6,641 pcs. - if ordered today
Total Price:
13.59 € *
Price list
Quantity
Price per unit*
1 pcs.
13.5898 €
10 pcs.
12.6259 €
25 pcs.
11.7810 €
50 pcs.
10.7100 €
*incl. VAT plus shipping costs
Subject to prior sale
D-Sub Backshells and Clamps, 5207908-1, AMP
Grommets: Without, D-Shaped Connector Accessories: Cable Clamp Kit, Color: Black, Cable Clamp Type: Box and Lid, Cable Exit Angle: 180° (In-Line),90° (Right Angle), Screw & Hole Thread Size: 14702, Cable Insulation Diameter Range: 4.06 mm, Compatible With Connector Shell Size: 1, Shielded: No, Packaging Method: Kit, Comment: All parts are packaged unassembled.,Each kit is comprised of a cable clamp and male screw retainer hardware (2 each).
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Shell size | 1 (DE) | |
| Cable Outlet | straight 180°, angled 90° | |
| Cable diameter | 4.06 mm | |
| Shell Material | PP | |
| Type of locking | locking screw 4-40 UNC | |
| Colour | black |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85389091 |
| Country of origin | IN |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
