8-338168-2 | AMP
D-Sub plug, 9 pole, standard, equipped, angled, solder pin, 8-338168-2
Unit Price (€ / pc.)
5.1051 € *
Available: 13 pcs.
Available in 5 Days: 2,164 pcs. - if ordered today
Total Price:
5.11 € *
Price list
Quantity
Price per unit*
1 pcs.
5.1051 €
10 pcs.
4.7362 €
25 pcs.
4.4268 €
50 pcs.
4.0222 €
*incl. VAT plus shipping costs
Subject to prior sale
D-Sub plug, 8-338168-2, AMP
PCB D-Sub Connector, Plug, Cable-to-Board, 9 Position, 2.74 mm Centerline, 2 Row, Size 1, Round, Standard profile.
Features
- Flame retardant thermoplastic housing material
- Low cost front Metal-Shell design
- Shell material: Steel, tin-plated
- Contact material: Phosphor-Bronze
Applications
- For signal applications
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2.74 mm | |
| Attachment (rear panel) | metal bracket with through hole | |
| Additional parts | equipped | |
| Assembly | angled | |
| Contact connection | solder pin | |
| Pin number | 9 pole | |
| Performance level | 2 | |
| Version | pin header | |
| Type of locking | threaded insert 4-40 UNC | |
| Pole image | standard |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
