553443-4 | AMP
D-Sub socket, 50 pole, standard, equipped, straight, press-in connection, 553443-4
Order No.: 37P1627
EAN: 4099889787337
MPN:
553443-4
Unit Price (€ / pc.)
8.2586 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
8.26 € *
Price list
Quantity
Price per unit*
1 pcs.
8.2586 €
10 pcs.
7.6755 €
25 pcs.
7.1638 €
50 pcs.
6.5093 €
*incl. VAT plus shipping costs
Subject to prior sale
D-Sub socket, 553443-4, AMP
PCB D-Sub Connector, Receptacle, Cable-to-Board, 50 Position, 2.16 mm Centerline, 2 Row, Standard profile, Vertical, PCB mount retention.
Features
- Unsealable
- Unshielded
- Preloaded: Yes
- Contact base material: Copper alloy
Applications
- For signal applications
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Attachment (rear panel) | through hole | |
| Pin number | 50 pole | |
| Type of locking | threaded insert 4-40 UNC | |
| Contact connection | press-in connection | |
| Pole image | standard | |
| Assembly | straight | |
| Grid | 2.16 mm | |
| Version | socket header | |
| Additional parts | equipped |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
