5-747905-2 | AMP

D-Sub socket, 9 pole, standard, equipped, straight, solder cup, 5-747905-2

Order No.: 55F429
EAN: 4099889806809
MPN:
5-747905-2
5-0747905-2
Series: AMPLIMITE
5-747905-2 AMP D-Sub Connectors Image 1
5-747905-2 AMP D-Sub Connectors Image 2
Image may differ
Unit Price (€ / pc.)
4.6410 € *
Available: 148 pcs.
Available in 5 Days: 11,039 pcs. - if ordered today
Total Price:
4.64 € *
Price list
Quantity
Price per unit*
1 pcs.
4.6410 €
10 pcs.
4.3197 €
25 pcs.
4.0222 €
50 pcs.
3.6652 €
*incl. VAT plus shipping costs
Subject to prior sale

Socket headers with solder contacts, type TE Connectivity/AMP HD-20 5-7479...-2.

with metal hood, ground connection and Galvanized outer housing. Contact material: phosphor bronze.Contact finish: 0.76 µm gold plating on nickel primer. Housing material: glass fiber-reinforced polyester, UL 94 V-0. Color: black. Material metal bracket: tinned steel. Rated current: max. 6.0 A. Insulation resistance:min. 500 Mohm. Dielectric strength: min. 1000 VAC. Operating temperatures: - 55 to +105 °C. Mounts:UNC 4-40 nut, UNC 4-40 screw lock, or 3.1 mm through hole.

Technical attributes (type, number of poles, dimensions, mounting, with/without integrated mounting clips): 5-747905-2, 9-pole, A 30.8, B 24.99

Technical specifications
Filter Property Value
Additional parts equipped
Pole image standard
Grid 2.77 mm
Attachment (rear panel) through hole
Version socket header
Contact connection solder cup
Type of locking through hole
Assembly straight
Pin number 9 pole
Logistics
Property Value
Country of origin CN
Customs tariff number 85389099
Compliance
Property Value
SVHC free Yes
RoHS conform Yes
Date of RoHS guidelines 3/31/15
