3-338169-2 | AMP

D-Sub plug, 15 pole, standard, equipped, angled, solder pin, 3-338169-2

Order No.: 55F4481
EAN: 4099889806878
MPN:
3-338169-2
3-0338169-2
Series: AMPLIMITE
3-338169-2 AMP D-Sub Connectors Image 1
3-338169-2 AMP D-Sub Connectors Image 2
Image may differ
Unit Price (€ / pc.)
8.7108 € *
Available: 41 pcs.
Available in 5 Days: 71 pcs. - if ordered today
Total Price:
8.71 € *
Price list
Quantity
Price per unit*
1 pcs.
8.7108 €
10 pcs.
8.0087 €
50 pcs.
7.2947 €
100 pcs.
6.5688 €
*incl. VAT plus shipping costs
Subject to prior sale

D-Sub plug, 3-338169-2, AMP

Right-angle mounting plug connector with Boardlock.

Features

  • Flame retardant thermoplastic housing material
  • Low cost front Metal-Shell design
  • Integral boardlock feature secures connector to PC board prior to soldering
  • Shell material: Steel, tin-plated
Technical specifications
Filter Property Value
Attachment (rear panel) metal bracket with PCB locking
Pin number 15 pole
Type of locking threaded insert 4-40 UNC
Contact connection solder pin
Pole image standard
Assembly angled
Performance level 2
Grid 2.74 mm
Version pin header
Additional parts equipped
Logistics
Property Value
Customs tariff number 85366990
Country of origin TW
Compliance
Property Value
Substance description Lead
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free No
