Box Mount D-Sub Connector, 1757827-4, TE Connectivity
Product Type: Connector, Connector and Housing Type: Plug, Connector System: Cable-to-Board, D-Sub Shell Size: 4, Sealable: No, PCB Mount Orientation: Vertical, Number of Positions: 37, Power/Signal/Coax Combination: No, Shell Plating Material: Zinc, Non-Magnetic: No, Contact Base Material: Brass or Beryllium Copper, Contact Type: Pin, D-Sub Contact Size: 20, Contact Current Rating (Max): 5 A, Termination Post Length: 3.95 mm, Mounting Hole Diameter: 3.05 mm, Centerline (Pitch): 2.77 mm, Post Diameter: .76 mm, Operating Temperature Range: -55 – 125 °C, ULTRA-LITE Connector: No, Circuit Application: Signal, NASA Qualification: No., Comment: "Z" is stamped on connectors following M24308 part number as required. "Z" designates zinc shell plating.
