1-1393480-8 | AMP
D-Sub socket, 15 pole, standard, equipped, straight, solder pin, 1-1393480-8
Order No.: 52F2570
EAN: 4099889805710
MPN:
1-1393480-8
V23529-B1121-B215
D-Sub socket, 1-1393480-8, AMP
Solder D-Sub Connector, Receptacle, Wire-to-Board, 15 Position, Size 2, Mating Retention, 2.74 mm Centerline, Printed Circuit Board, Signal.
Features
- Shell material: Steel
- Insert flammability rating UL 94V-0
- Unsealable
- Contact base material: Copper alloy
Applications
- For signal applications
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 15 pole | |
| Version | socket header | |
| Contact connection | solder pin | |
| Grid | 2.74 mm | |
| Pole image | standard | |
| Additional parts | equipped | |
| Assembly | straight | |
| Type of locking | through hole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | NL |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
