927842-2 | AMP

Name: Pin contact, 0.1-0.5 mm², AWG 20-17, crimp connection, 927842-2
Brand: AMP
SKU: 72P2353
Availability: OutOfStock

Pin contact, 0.1-0.5 mm², AWG 20-17, crimp connection, 927842-2

Order No.: 72P2353

EAN: 4099889987478

MPN:

927842-2

Image may differ

Key Specification:

Version pin contact

Cable cross-section 0.1-0.5 mm²

AWG cross-section AWG 20-17

Contact connection crimp connection

Contact material copper-tin

Unit Price (€ / pc.)

0.4879 € *

Standard delivery time from the manufacturer is: 21 Weeks

Total Price:

0.49 € *

Price list

Quantity

Price per unit*

1 pcs.

0.4879 €

10 pcs.

0.4284 €

50 pcs.

0.3689 €

100 pcs.

0.3332 €

*incl. VAT plus shipping costs

Subject to prior sale

Description

Connector contact, Pin, Tin, Pre-Tin, 250 VAC, Locking lance contact retention, Discrete wire, 20-17 AWG Wire size.

Technical specifications

Filter	Property	Value
	Contact surface mating area	tin-plated
	AWG cross-section	AWG 20-17
	Contact surface Connection range	tin-plated
	Contact connection	crimp connection
	Cable cross-section	0.1-0.5 mm²
	Version	pin contact
	Contact material	copper-tin
	Insulation diameter	1.4-2.3 mm
