925856-1 | AMP
Pin contact, 1.5-2.5 mm², AWG 15-13, crimp connection, tin-plated, 925856-1
Order No.: 34P9826
EAN: 4099889636628
MPN:
925856-1
Unit Price (€ / pc.)
0.0536 € *
Available in 5 Days: 210,000 pcs. - if ordered today
Crimp wire pins, tabs and ferrules, 925856-1, AMP
Crimp Wire Pin, Tab & Ferrule Barrel Type: Open Barrel, Insulated: No, Crimp Wire Pin, Tab & Ferrule Plating Material: Pre-Tin, Terminal & Splice Type: Pin, Crimp Wire Pin, Tab & Ferrule Terminal Type: Pin, Crimp Wire Pin, Tab & Ferrule Pin Diameter: 1.6 mm, Crimp Wire Pin, Tab & Ferrule Terminal Orientation: Straight, Wire Insulation Support: Without, Wire Size: 15 - 13 AWG, Wire Size: 1.5 - 2.5 mm², Wire Size: 3256 - 5178 CMA, Barrel Inside Diameter: 0.8 mm, Crimp Wire Pin, Tab & Ferrule Material Thickness: 0.25 mm Heavy Duty: No, Packaging Quantity: 30000, Crimp Wire Pin, Tab & Ferrule Packaging Method: Reel, Comment: According to DIN 46228, Part 3.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | pin contact | |
| Cable cross-section | 1.5-2.5 mm² | |
| AWG cross-section | AWG 15-13 | |
| Contact connection | crimp connection | |
| Contact material | brass | |
| contact surface | tin-plated | |
| Contact surface Connection range | tin-plated |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 30,000 pieces |
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
