925590-1 | AMP
Receptacle, 0.5-1.5 mm², AWG 20-15, crimp connection, tin-plated, 925590-1
Order No.: 36P3341
EAN: 4099889644500
MPN:
925590-1
Unit Price (€ / pc.)
0.1107 € *
Available: 0 pcs.
Available in 5 Days: 44,000 pcs.
Leadtime: 29 Weeks **
Total Price:
442.68 € *
Price list
Quantity
Price per unit*
4000 pcs.
0.1107 €
8000 pcs.
0.1095 €
*incl. VAT plus shipping costs
**Subject to prior sale
Socket contact, 925590-1, TE Connectivity
Receptacle Style: 180°, Sealable: No, Primary Locking Feature: Locking Lance, Wire Type: Copper, Crimp Type: F-Crimp, Terminal & Splice Type: Receptacle, Mating Tab Width: 2.8 mm, Mating Tab Thickness: 0.8 mm, Interface Plating: Tin (Sn), Termination Method: Crimp, Wire Size: 0.5 - 1.5 mm², Wire Size Search: 16 AWG, 17 AWG, 18 AWG, 19 AWG,20 AWG, Wire Size Search: 0.5 mm², 0.6 mm², 0.75 mm², 0.85 mm², 1 mm², 1.25 mm², 1.3 mm², 1.5 mm², Wire Insulation Diameter: 2 - 3 mm, Operating Temperature Range: -40 - 110 °C.
Technical specifications
| Version | Buchsenkontakt | |
| AWG cross-section | AWG 20-15 | |
| Insulation diameter | 2-3 mm | |
| Contact connection | Crimpanschluss | |
| Contact material | Messing | |
| contact surface | verzinnt | |
| Cable cross-section | 0,5-1,5 mm² |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
