66602-7 | AMP

Name: Pin contact, 0.8-2 mm², AWG 18-14, crimp connection, 66602-7
Brand: AMP
SKU: 72P0877
Price: 1.61 EUR
Availability: OutOfStock

Pin contact, 0.8-2 mm², AWG 18-14, crimp connection, 66602-7

Order No.: 72P0877

EAN: 4099889986662

MPN:

66602-7

Series: Type III+

Image may differ

Key Specification:

Version pin contact

Cable cross-section 0.8-2 mm²

AWG cross-section AWG 18-14

Contact connection crimp connection

Contact material brass

Ordering Information:

not to be sold to private customers

Download Datasheet Technical specifications

Unit Price (€ / pc.)

1.6065 € *

Available: 0 pcs.

Available in 5 Days: 360 pcs.

Leadtime: 1 Week **

Add to Cart

Total Price:

1.61 € *

Price list

Quantity

Price per unit*

100 pcs.

1.6065 €

400 pcs.

1.2971 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Power contact, 66602-7, AMP

Power contact, Contact, Precious metal, 18 -14 AWG Wire size, 0.8 -2 mm² Wire size, Wire & Cable, Crimp, Power & Signal, Pin.

Technical specifications

	Version	pin contact
	AWG cross-section	AWG 18-14
	Insulation diameter	2.79-3.81 mm
	Contact connection	crimp connection
	Contact material	brass
	Contact surface Connection range	tin-plated
	Contact surface mating area	gold-plated
	Cable cross-section	0.8-2 mm²
