5227677-1 | AMP

BNC socket 50 Ω, solder connection, angled, 5227677-1

Order No.: 78F2483
EAN: 4099889831290
MPN:
5227677-1
0-5227677-1
Series: BNC
5227677-1 AMP Coaxial Connectors Image 1
5227677-1 AMP Coaxial Connectors Image 2
Image may differ
Unit Price (€ / pc.)
8.33 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Total Price:
8.33 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
8.33 €

RF Coaxial connector, 5227677-1, AMP

The 5227677-1 is a BNC connector, 50 Ohm with bayonet locking coupling and provides highly reliable, quick connect/disconnect coaxial connections. In addition to a variety of crimp type terminations, connectors are furnished in field replaceable and twist-on styles. This connector is designed around the mil-specifications, but utilize low-cost materials, offering comparable mechanical and electrical performance.

Features

  • Fully intermateable with comparable BNC UG/U connectors
  • Twist-on connectors require no special tooling for application to the cable
  • Choice of different dielectrics
  • Low VSWR

Applications

  • Broadband, networking, signal management
  • Video distribution, including HDTV
  • Industry standard interface, commercial and military aerospace
Technical specifications
Connector BNC
Contact connection solder connection
Version socket
Design angled
Contact material phosphor bronze
Impedance 50 Ω
Logistics
Country of origin CN
Customs tariff number 85366990
Original Packaging Bar with 35 pieces
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
