160298 | AMP
Insulated ring cable lug, 2.7-6.6 mm², AWG 12 to 10, 8.3 mm, M8, yellow, 160298
Unit Price (€ / pc.)
0.5831 € *
Available: 300 pcs.
Available in 5 Days: 5,762 pcs. - if ordered today
Total Price:
0.58 € *
Price list
Quantity
Price per unit*
1 pcs.
0.5831 €
10 pcs.
0.5474 €
25 pcs.
0.5117 €
50 pcs.
0.4641 €
*incl. VAT plus shipping costs
Subject to prior sale
Cable lug, 160298, AMP
Regular Wire, Closed Barrel, Straight, 300 V, 5/16,M8, 5180 – 13100 CMA
Technical Data
- Version: Ring cable lug
- AWG cross-section AWG 12 to 10
- Colour: yellow
- Material: Copper, tin-plated
- Cable cross-section 2.7 to 6.6 mm²
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material Insulation | nylon | |
| max. operating temperature | 170 °C | |
| AWG cross-section | AWG 12 to 10 | |
| Colour | yellow | |
| Material | copper, tin-plated | |
| Isolated | Yes | |
| Thread size | M8 | |
| Hole diameter | 8.3 mm | |
| Version | ring cable lug | |
| Cable cross-section | 2.7-6.6 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369095 |
| Country of origin | PT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
