Crimp Wire Pins, Tabs and Ferrules, 1-1377174-1, AMP
Crimp Wire Pin, Tab & Ferrule Barrel Type: Closed Barrel, Crimp Wire Pin, Tab & Ferrule Wire/Cable Type: Discrete Wire, Sealable: No, Insulated: Yes, Support Style: Insulation Support, Insulation Color: Red, Crimp Wire Pin, Tab & Ferrule Plating Material: Tin, Terminal Length: 9.9 mm, Terminal & Splice Type: Pin, Crimp Wire Pin, Tab & Ferrule Terminal Type: Wire Pin, Crimp Wire Pin, Tab & Ferrule Pin Diameter: 1.8 mm, Crimp Wire Pin, Tab & Ferrule Terminal Orientation: Straight, Bullet Terminal: Without, Wire Insulation Support: With, Accepts Wire Insulation Diameter Range: 3.56 mm, Wire Size: 22 – 16 AWG, Wire Size: .25 – 1.6 mm², Wire Size: 493 – 3158 CMA, Barrel Inside Diameter: 3.68 mm, Insulation Requirement: Partially Insulated, Operating Temperature Range: 105 °C, Heavy Duty: No, Packaging Quantity: 100, Crimp Wire Pin, Tab & Ferrule Packaging Method: Box, Barrel Color: Red
