RK14 K122 10K LIN | ALPS
Dual film potentiometer, 10 kΩ, 0.05 W, linear, solder pin, RK14 K122 10K LIN
Unit Price (€ / pc.)
2.2729 € *
Standard delivery time from the manufacturer is: 24 Weeks
Potentiometer, RK14 K122 10K LIN, ALPS
This potentiometer is designed with a closed structure to enhance its resistance against dust and flux.
Applications
- For volume, tone and balance adjustments in audio equipment
- For controlling mixing consoles and electronic musical instruments
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | dual film potentiometer | |
| axle diameter | 6 mm | |
| min. operating temperature | -10 °C | |
| max. operating temperature | 70 °C | |
| Mechanic rotary range | 300 ° | |
| Width | 7.5 mm | |
| ohmic resistance | 10 kΩ | |
| Power | 0.05 W | |
| Track Taper | linear | |
| Length | 14 mm | |
| Connection | solder pin | |
| Contact distance | RM 2 | |
| Assembly | angled |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Ammopack with 100 pieces |
| Customs tariff number | 85334010 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
