1977223-1 | Alcoswitch
Short-stroke pushbutton, 1 Form A (N/O), 50 mA/24 VDC, unlit , actuator (blue, L 0.7 mm), 100 g, SMD, 1977223-1
Order No.: 12G511
MPN:
1977223-1
FSM2JSMLS=6MM TACT SWITCH, SMT 100gf
Unit Price (€ / pc.)
0.2380 € *
Standard delivery time from the manufacturer is: 25 Weeks
Total Price:
2.38 € *
Price list
Quantity
Price per unit*
10 pcs.
0.2380 €
100 pcs.
0.2261 €
500 pcs.
0.2023 €
1000 pcs.
0.1904 €
*incl. VAT plus shipping costs
Subject to prior sale
Tactile switch, 1977223-1, Alcoswitch
50 mA Tactile Switch, Round Actuator, NO, Copper Alloy, Silver Contact Plating, Low Profile, 24 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact material | silver-plated | |
| actuator length | 0.7 mm | |
| Connection | SMD | |
| Actuator colour | blue | |
| actuating force | 100 g | |
| Latching switching function | 1 Form A (N/O) | |
| Height | 4.3 mm | |
| illuminated | No | |
| Length | 6 mm | |
| Width | 6 mm | |
| Breaking capacity | 50 mA/24 VDC |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
