J-Y(ST)Y 10X2X0,8 | Telecommunication Cables
Telephone cable, 20-wire, J-Y(ST)Y, 10 x 2 x 0.8 mm, gray, PVC, J-Y(ST)Y 10X2X0,8
Unit Price (€ / mtr.)
2.0111 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
201.11 € *
Price list
Quantity
Price per unit*
100 mtr.
2.0111 €
500 mtr.
1.8564 €
*incl. VAT plus shipping costs
Subject to prior sale
Lead J-Y(ST)Y 10X2X08
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | gray | |
| Core colour sequence | DIN VDE 0815 | |
| Core insulation material | PVC | |
| Inner diameter | 0.8 mm | |
| Temperature range (active) | -5 °C to 50 °C | |
| Cable structure | 10 x 2 x 0.8 mm | |
| Temperature range (unmoved) | -30 °C to 70 °C | |
| Number of cores | 20 | |
| Outer diameter | 13.1 mm | |
| Material | PVC | |
| Cable material | copper, bright |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444991 |
| Country of origin | QU |
| Original Packaging | Ring with 100 meters |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
