05339 A | Power Transformers

Name: Universal transformer, 30 VA, 20 V/24 V/30 V, 0.5 A, 05339 A
SKU: 35C170
Availability: OutOfStock

Universal transformer, 30 VA, 20 V/24 V/30 V, 0.5 A, 05339 A

Order No.: 35C170

EAN: 4099891343842

MPN:

05339 A

Image may differ

Key Specification:

Output power 30 W

Primary voltage 230 V

Secondary voltage (1) 20 V

Secondary voltage (2) 24 V

Secondary voltage (3) 30 V

Show 7 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

89.131 € *

Standard delivery time from the manufacturer is: 6 Weeks

Add to Cart

Total Price:

445.66 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Universal transformers, type UE 8

Electrically isolated windings. Secondary 2 x 0, 20, 24, 30 V. The two secondary windings can be wired in serial or parallel mode to obtain the following secondary voltages: 4, 6, 8, 10, 12, 14, 16, 20, 24, 26, 28, 30, 34, 36, 40, 44, 48, 50, 54, 60 V.

Technical specifications

Filter	Property	Value
	Secondary amperage 1	0.5 A
	Output power	30 W
	Secondary voltage (1)	20 V
	Secondary voltage (3)	30 V
	Primary voltage	230 V
	Secondary voltage (2)	24 V
	Height	71 mm
	Length	57.8 mm
	Width	57.8 mm
