05334 A | Power Transformers

Name: Universal transformer, 50 VA, 10 V/12 V/15 V, 1.67 A, 05334 A
SKU: 35C120
Availability: InStock

Universal transformer, 50 VA, 10 V/12 V/15 V, 1.67 A, 05334 A

Order No.: 35C120

EAN: 4099891343798

MPN:

05334 A

Image may differ

Key Specification:

Output power 50 W

Primary voltage 230 V

Secondary voltage (1) 10 V

Secondary voltage (2) 12 V

Secondary voltage (3) 15 V

Show variants: 7

Download Datasheet Technical specifications

Unit Price (€ / pc.)

49.147 € *

Standard delivery time from the manufacturer is: On Request

Total Price:

49.15 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Universal transformers, type UE 3

Electrically isolated windings (types UE 3 with protective winding). Secondary 2 x 0, 10, 12, 15 V. The two secondary windings can be wired in serial or parallel mode to obtain the following secondary voltages: 2, 3, 4, 5, 6, 7, 8, 10, 12, 13, 14, 15, 17, 18, 20, 22, 24, 25, 27, 30 V.

Technical specifications

Filter	Property	Value
	Output power	50 W
	Primary voltage	230 V
	Secondary voltage (1)	10 V
	Secondary voltage (2)	12 V
	Secondary voltage (3)	15 V
	Secondary amperage 1	1.67 A
	Length	74 mm
	Width	63.5 mm
	Height	80 mm
