H07V-K 16/7,4 SW | Insulated stranded wires
PVC-stranded wire, high flexible, H07V-K, 16 mm², black, outer Ø 7.4 mm, H07V-K 16/7,4 SW
Unit Price (€ / mtr.)
3.3558 € *
Available: 168 mtr.
Leadtime: 4 Weeks **
Total Price:
3.36 € *
Price list
Quantity
Price per unit*
1 mtr.
3.3558 €
10 mtr.
3.0821 €
100 mtr.
2.8560 €
500 mtr.
2.6775 €
1000 mtr.
2.5109 €
*incl. VAT plus shipping costs
**Subject to prior sale
Stranded wire, H07V-K 16/7,4 SW, N.A.
PVC stranded wire H07V-K according to VDE 0281, cross-section: 16 mm², O.D. 7.4 mm, conductor material: copper, bare. Nominal voltage U0/U: 450/750 V.
Technical specifications
| Rated voltage | 750 V | |
| Temperature range (unmoved) | -30 °C to 70 °C | |
| Core insulation material | PVC | |
| Conductor category | CL.5 = fine stranded | |
| Standard number | VDE 0281 | |
| Halogen free | No | |
| Cable cross-section | 16 mm² | |
| Outer diameter | 7.4 mm | |
| Temperature range (active) | -5 °C to 70 °C | |
| Colour | black | |
| Rated voltage U0 | 450 V | |
| Cable material | copper, bright | |
| Test voltage | 2.5 kV |
Download
Logistics
| Country of origin | DE |
| Original Packaging | Ring with 100 meters |
| Customs tariff number | 85444995 |
Compliance
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
