NC5MBV-B | Neutrik
XLR panel plug, 5 pole, gold-plated, metal, NC5MBV-B
Unit Price (€ / pc.)
5.5573 € *
Available: 0 pcs.
Leadtime: On Request **
XLR plug, NC5MBV-B, NEUTRIK
5 pole male XLR receptacle, grounding: separate ground contact to mating connector shell and front panel, vertical PCB mount, black chrome shell.
Features
- Smallest XLR receptacles, highest packing density
- Metal mounting flange featuring continuous circumferential ground contact to chassis for best EMC and RF protection
Technical specifications
| Version | panel plug | |
| Assembly | PCB mounting | |
| Enclosure | metal | |
| Pin number | 5 pole | |
| Type of locking | snap lock | |
| Rated voltage | 50 V | |
| Rated current | 3 A | |
| Contact connection | solder connection | |
| contact surface | gold-plated | |
| Colour | black |
Download
Logistics
| Country of origin | LI |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
