69001-846 | SCHROFF

Name: Connector Type F, EN 60603, DIN 41612, Male,48 Contacts, Solder Pins, 2.9 mm
Brand: SCHROFF
SKU: 85H6686
Price: 7.29 EUR
Availability: InStock

Connector Type F, EN 60603, DIN 41612, Male,48 Contacts, Solder Pins, 2.9 mm

Order No.: 85H6686

EAN: 4036088067853

MPN:

69001-846

Image may differ

Key Specification:

Version male connector

Contact type pin

Pin number 48 pole

Grid 5.08 mm

Connection solder pin

Show 39 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

7.2947 € *

Available: 5 pcs.

Leadtime: 1 Week **

Total Price:

7.29 € *

Price list

Quantity

Price per unit*

1 pcs.

7.2947 €

100 pcs.

6.5688 €

200 pcs.

5.9143 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Male / Female DIN connector form F. Requirement class 2 as per EN 60603 (DIN 41642).
