24571-942 | SCHROFF

Name: 19 inch enclosure, 6/7 U, 28 HP, (W x H x D) 164.4 x 310.35 x 255.5 mm, aluminum, gray, 24571-942
Brand: SCHROFF
SKU: 85H4278
Price: 221.76 EUR
Availability: OutOfStock

19 inch enclosure, 6/7 U, 28 HP, (W x H x D) 164.4 x 310.35 x 255.5 mm, aluminum, gray, 24571-942

Order No.: 85H4278

EAN: 4036088033438

MPN:

24571-942

Series: RatiopacPro Air

Image may differ

Key Specification:

Version enclosure, 6/7 U, 28 HP

Width 164.4 mm

Height 310.35 mm

Depth 255.5 mm

Material aluminum

Show 42 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

221.7565 € *

Available: 0 pcs.

Leadtime: 2 Weeks **

Add to Cart

Total Price:

221.76 € *

*incl. VAT plus shipping costs

**Subject to prior sale
