H12WD48125PG | CRYDOM
Solid state relay, 660 VAC, zero voltage switching, 4-32 VDC, 125 A, PCB mounting, H12WD48125PG
Unit Price (€ / pc.)
140.2415 € *
Available: 0 pcs.
Available in 5 Days: 2 pcs.
Leadtime: 1 Week **
Solid State Relay, H12WD48125PG, CRYDOM
Solid State Relay, Panel Mount, IP00, 660VAC/125A, DC In, Zero Cross, IOP, LED
Features
- Ratings from 25A to 125A @ 48-660 VAC
- Low off-state leakage current (snubberless)
- SCR output for heavy industrial loads
- Zero Voltage or instantaneous turn-on outputs
- UL/CSA/VDE Approved, CE Compliant to EN60950-1
- Improved SEMS screw and washer
Technical specifications
| LED display | Yes | |
| Assembly | PCB mounting | |
| Rated current | 125 A | |
| Switching Mode | zero voltage switching | |
| Voltage V RRM (peak reverse voltage) | 1.2 kV | |
| Voltage | 4-32 VDC | |
| Control Voltage | 660 VAC |
Download
Logistics
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
