205234 | PEPPERL+FUCHS
Inductive proximity switch
Order No.: 28G1039
EAN: 4099889430424
MPN:
205234
RLK31-8-2500-IR/31/115
Unit Price (€ / pc.)
126.1638 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Diffuse mode sensors, type Pepperl+Fuchs RLK 31-8.
Energetic; Operating voltage: 12 to 240 VDC/24 to 240 VAC. Sensing range: 0 to 2500 mm, variable. Switching output: relay, 1 x electrically isolated CO. Switching current: max. 3,0 A. Connection: 2.0 m fixed cable, 5-wire. Degree of protection: IP 67. Housing: PC. Operating temperatures: –25 to +60 °C. Certifications: CCC.
Type: 205234, diffuse mode sensor
Technical specifications
| Connection | cable connection | |
| Activation time | 25 ms | |
| Version | diffuse mode sensor | |
| Switching logic | dark ON | |
| Degree of protection (IP) | IP67 | |
| Voltage | 24-240 V AC/DC | |
| Power supply | 40 mA |
Download
Logistics
| Country of origin | VN |
| Customs tariff number | 85365080 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | lead, 4,4'-isopropylidenediphenol |
