4610X-101-102LF | Bourns Electronics GmbH
Resistor network, SIP-9, 1 kΩ, 0.2 W, ±2 %, 9 resistors, 4610X-101-102LF
Unit Price (€ / pc.)
0.211 € *
Available: 89 pcs.
Leadtime: 19 Weeks **
Total Price:
0.21 € *
Price list
Quantity
Price per unit*
1 pcs.
0.211 €
10 pcs.
0.195 €
50 pcs.
0.160 €
2000 pcs.
0.119 €
*plus VAT and shipping costs
**Subject to prior sale
Resistance networks, type Bourns 4600X.
Thickfilm, SiL (Single-in-Line) resistors (same value), interconnected, common connection (bussed resistors)
With 9 resistors, 10-pole, type 4610X-101-RC.
Technical specifications
| Temperature coefficient | ±100 ppm/°C | |
| Assembly | THT | |
| Enclosure | SIP-9 | |
| Width | 2.49 mm | |
| Height | 5.08 mm | |
| Power | 0.2 W | |
| Length | 25.35 mm | |
| Number of resistors | 9 | |
| Tolerance | ±2 % | |
| max. operating temperature | 125 °C | |
| ohmic resistance | 1 kΩ |
Download
Logistics
| Country of origin | JP |
| Customs tariff number | 85332100 |
| MSL | MSL 1 |
| Original Packaging | Bulk with 200 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
